Arons Podium Controller
Arons Podium Controller
- PROGRAMMABLE DIGITAL CONTROLLER
- INFORMATION FUNCTION DISPLAY
- DUAL PC TOUCH COMPATIBILITY
- DIGITAL MIC/SOURCE VOLUME CONTROL THROUGH FRONT PANEL
- INBUILT PHANTOM POWER WITH CLASS-D AMPLIFIER
- AUTO INPUT SOURCE SELECTION
- ONE-TOUCH ON/OFF OPERATION FOR ALL DEVICES
- RS-232 HEX COMMUNICATION WITH MAJOR PROJECTOR BRANDS & PC
- PC POWER OFF COMMAND THROUGH USB PORT
- KEY LOCK OPTION THROUGH RFID (OPTIONAL)
- KEY LOCK OPTION THROUGH MAGNETIC LOCK
- CONTROLLER WITH INBUILT CLASS-D AUDIO AMPLIFIER
- AUTOMATIC SCREEN TILT TO CLOSE POSITION AFTER POWER OFF
- DOCUMENT CAMERA COMPATIBILITY
- WIRELESS MICROPHONE COMPATIBILITY
- BLUETOOTH AUDIO COMPATIBILITY
- MIRACAST COMPATIBILITY
Description
- PROGRAMMABLE DIGITAL CONTROLLER
- INFORMATION FUNCTION DISPLAY
- DUAL PC TOUCH COMPATIBILITY
- DIGITAL MIC/SOURCE VOLUME CONTROL THROUGH FRONT PANEL
- INBUILT PHANTOM POWER WITH CLASS-D AMPLIFIER
- AUTO INPUT SOURCE SELECTION
- ONE-TOUCH ON/OFF OPERATION FOR ALL DEVICES
- RS-232 HEX COMMUNICATION WITH MAJOR PROJECTOR BRANDS & PC
- PC POWER OFF COMMAND THROUGH USB PORT
- KEY LOCK OPTION THROUGH RFID (OPTIONAL)
- KEY LOCK OPTION THROUGH MAGNETIC LOCK
- CONTROLLER WITH INBUILT CLASS-D AUDIO AMPLIFIER
- AUTOMATIC SCREEN TILT TO CLOSE POSITION AFTER POWER OFF
- DOCUMENT CAMERA COMPATIBILITY
- WIRELESS MICROPHONE COMPATIBILITY
- BLUETOOTH AUDIO COMPATIBILITY
- MIRACAST COMPATIBILITY
| No. | Key | Front Key Functions |
|---|---|---|
| 1 | MIC | Key for gooseneck mic ON/OFF |
| 2 | SOURCE | Manual selection for input source HDMI/VGA/Other |
| 3 | MUTE | Audio mute for PC and gooseneck mic |
| 4 | VOL (-) | To reduce audio level of PC and gooseneck mic |
| 5 | VOL (+) | To increase audio level of PC and gooseneck mic |
| 6 | POWER | Power button ON/OFF internal PC |
| 7 | SCREEN DOWN | To adjust downward tilt position of touch screen |
| 8 | SCREEN UP | To adjust upward tilt position of touch screen |
| 9 | DISPLAY | Real-time functional information of podium |
| 10 | USB | To access PC through USB terminal |
| 11 | POWER LED | Red colour for PC OFF, green colour for PC and podium “ON” |
| 12 | MUTE LED | Mute LED will blink if mute function is “ON” |
| 13 | SOURCE LED | Source LED indicates input source status |
| 14 | MIC LED | Mic LED will illuminate blue when mic is “ON” |
