AI Features
The Text Recognition Pen: Convert, translate, edit text
AI-Powered Search & Learning: Explore, learn, understand instantly
The Magical Pen: Sketch to Image
Shape Recognition: Sketch to perfect shapes
-
INPUT
HDMI: x2 (Frontx1:HDMI2.0 with CEC ; Rearx1: [HDMI2.0 with CEC/ ARC)x1]
Audio: x1 (3.5mm phone jack)
RS232: x1
OPS: x1 (Optional Intel Standard OPS)
WiFi: x1 (Built-in)
-
OUTPUT
HDMI: x1 (1920×1080 @60Hz)
Audio: x1 (3.5mm Line out)
SPDIF: x1
-
LAN
RJ45: x1
-
USB
Type A: USB3.0:Front x1 , USB2.0: Front x1 , Rear x1 (support Android only)
Type B: USB 2.0:Front x1 , Rear x1
Type C: USB 2.0:Front x1 (data only), Rear x1 (data only)
-
SPEAKERS
2 x 20W
-
Embedded OS
Android 14 EDLA (A16 upgradable)
-
Power
Voltage: 100-240V AC
Consumption: 380W(Max) Off mode < 0.5W
-
ERGONOMICS
Wall Mount (VESA® ): 800 mm x 400 mm
-
OPERATING CONDITIONS
Temperature (º C): 0℃ ~ 40℃
Humidity: 10% ~ 80% RH non-condensing
-
DIMENSIONS (W x H x D)
Physical (inch / mm): 77.30×46.46×3.81(in.) / 1963.5×1180.1×96.7(mm)
Packaging (inch / mm): 81.06×50.87×6.89(in.) / 2059x1292x175(mm)
-
WEIGHT
Net (lb / kg): 132.50lb / 60.1kg
Gross (lb / kg): 153.88lb / 69.8kg
-
REGULATIONS
BIS, WPC
-
PACKAGE CONTENTS
1. 3m power India power plug x 1
2. 3m HDMI cable x 1
3. 3m Touch USB cable (USB2.0) x 1
4. Touch pen x 2
5. Remote control x 1
6. AAA battery x 2
7. Quick Start Guide with Compliance statement
8. Screw x 4 (wall mount
M8*25mm)
-
Compatible Slot-in PC
VPC35/37 series , VPCF5 series
