Optoma ZU920TST Ultra Bright Fixed Lens Laser Projector
At 9800 lumens with 4K and HDR compatibility, the ZU920TST features a dust-resistant IP5X certified optical engine for 24/7 operation capabilities, offering true maintenance-free projection for up to 30,000 hours of powerful performance in Eco mode. Other features include a motorised zoom, full motorised lens shift and built-in dual 10W speakers.
High brightness, colour precision and quiet operation, along with a short throw lens make this projector the ideal solution for a variety of end-user scenarios and professional environments, such as short throw digital signage, edge-blending and projection mapping, simulation and immersive installations.
The added control flexibility of HDBaseT and LAN make this projector an affordable install and forget solution.
Description
| Specification | Details |
|---|---|
| Display Technology | DLP™ |
| Native Resolution | WUXGA (1920 × 1200) |
| Brightness | 9,800 Lumens |
| Contrast Ratio | 3,000,000:1 |
| Native Aspect Ratio | 16:10 |
| Compatible Aspect Ratios | 4:3, 16:9, 16:10 |
| Displayable Colours | 1.07 Billion |
| Uniformity | 95% |
| Horizontal Keystone | ±30° |
| Vertical Keystone | ±30° |
| Screen Size | 50″ – 300″ (1.27 – 7.62 m) |
| Light Source | DuraCore Laser |
| Laser Life | Up to 30,000 Hours |
| Optical Engine | IP5X Certified Dust Resistant |
| Throw Ratio | 0.65:1 – 0.75:1 |
| Projection Distance | 0.7 – 16.6 m |
| Zoom | 1.15× Motorised |
| Focal Length | 9.69 – 11.19 mm |
| Lens Shift | Vertical ±110%, Horizontal ±50% |
| Native Offset | 50% |
| 360° Projection | Yes |
| 24/7 Operation | Yes |
| HDR Support | HDR Compatible |
| 3D Support | Full 3D |
| Noise Level | 36 dB (Min), 38 dB (Max) |
| Built-in Speakers | 2 × 10W |
| HDMI Inputs | 2 × HDMI 2.0 |
| VGA Input | 1 × VGA |
| Audio Input | 1 × 3.5 mm |
| HDMI Output | 1 × HDMI 2.0 |
| Audio Output | 1 × 3.5 mm |
| HDBaseT | 1 × HDBaseT |
| USB | 1 × USB-A (Power 1.5A) |
| 3D Sync | 1 × Input, 1 × Output |
| LAN | RJ45 |
| RS232 | Yes |
| Wired Remote | Yes |
| 12V Trigger | Yes |
| LAN Control | Yes |
| Wireless Networking | No |
| Security | Kensington Lock, Security Bar |
| Remote | Backlit ProAV Remote |
| Power Supply | AC 90–264V, 50/60Hz |
| Power Consumption | 265W (Min), 520W (Max) |
| Dimensions (W × D × H) | 480 × 376 × 144 mm |
| Net Weight | 14 kg |
| Gross Weight | 17.5 kg |
| Applications | Large Venues, Digital Signage, Edge Blending, Projection Mapping, Simulation, Immersive Installations |
| Package Contents | Power Cable, Backlit ProAV Remote, Quick Start Guide |
